ইমপ্যাক্ট মিল
The material is evenly fed into the grinding chamber by the feeding system, and is strongly impacted by the high-speed rotating crushing disc, and at the same time, it is subjected to various forces such as friction, shearing, and collision between the static disk and the ring gear, and is finally crushed.
কাজের নীতি
The material is evenly fed into the grinding chamber by the feeding system, and is strongly impacted by the high-speed rotating crushing disc, and at the same time, it is subjected to various forces such as friction, shearing, and collision between the static disk and the ring gear, and is finally crushed. The crushing movable disk and static disk can be combined in different structures to meet the crushing requirements of different materials. The structural forms we currently design include: hammer type, pin type, turbine type, and grinding disc type.
বৈশিষ্ট্য এবং সুবিধা
- It achieves smaller particle size than hammer mill at relatively reasonable energy consumption.
- Recent advances have improved heat removal from the mill using cryogenic conditions.
- Pin mill occupies little floor space.
- It has a wide range of applications; can be used in milling dry, moist or slurry materials.
- The two needle discs in the mill rotate at high speed in opposite directions;
- The fineness of the product is achieved by adjusting the speed of the dial;
- The machine is easy to clean, just open the grinding door;
- No sieve, smooth discharge, high capacity and low operation cost; dual power can be used to achieve a linear speed above 200m/s to obtain greater crushing power.
প্রযুক্তিগত পরামিতি
| Type | মডেল | 200 | 400 | 500 | 630 | 800 |
|---|---|---|---|---|---|---|
| Coarse powder | সূক্ষ্মতা (জাল) | 20 - 200 | 20 - 200 | 20 - 200 | 20 - 200 | 20 - 200 |
| গতি (মি/সেকেন্ড) | 75 - 85 | 75 - 85 | 75 - 85 | 75 - 85 | 75 - 85 | |
| Power（kw） | 7.5 | 18.5 | 22 | 37 | 55 | |
| Fine powder | সূক্ষ্মতা (জাল) | 60 - 300 | 60 - 300 | 60 - 300 | 60 - 300 | 60 - 300 |
| speed（m/s） | 100 - 120 | 100 - 120 | 100 - 120 | 100 - 120 | 100 - 120 | |
| Power（kw） | 11 | 30 | 37 | 55 | 75 | |
| Ultra fine powder | সূক্ষ্মতা (জাল) | 100-2500 | 100-2500 | 100-2500 | 100-2500 | 100-2500 |
| গতি (মি/সেকেন্ড) | 200-240 | 200-240 | -- | 200-240 | 200-240 | |
| Power（kw） | 11 x 2 | 30 x 2 | -- | 55 x 2 | 90 x 2 |
